> >>8X (Bc-835-Din-Rj45 Dc12-24V bemenet 5A X 5Ch kimenet, Din Rail 5Ch Cv Pwm Dmx5 H1E1
Alacsonyabb ár! 8X (Bc-835-Din-Rj45 Dc12-24V bemenet 5A X 5Ch kimenet, Din Rail 5Ch Cv Pwm Dmx5 H1E1 Nagyobb
Előző Következő

8X (Bc-835-Din-Rj45 Dc12-24V bemenet 5A X 5Ch kimenet, Din Rail 5Ch Cv Pwm Dmx5 H1E1

283475452717

Új termék

8X(Bc-835-Din-Rj45 Dc12-24V Input 5A X 5Ch Output, Din Rail 5Ch Cv Pwm Dmx5 H1E1

8X(Item Type:Dimmers; Features:DIN Rail 5CH DMX512 CV Decoder; Certification:ce,CCC,RoHS;Material: metal plastic; Model Number:BC-835-DIN-RJ45; Max. Load Power:300W(12V)/600W(24V);Input voltage:DC12V-DC24V; Max load current:5A*5CH; Grey Scale:4096 levels*5; Input Signal:DMX512/1990; Output Signal:Constant Voltage PWM; Decode Channel:5CH; DMX512 socket:RJ45; Dimension: L111xW46xH66(mm); Weight (G.W) : 135g; colour: White; Material: metal plastic;
It adopted advanced micro-computer control technology to transfer standard DMX512/1990 signal to PWM signal. user can choose 1~5 output channels, 4096 Grey Scales. It can be used as DMX512 master or as DMX decoder to connect computerized digital output console with analog silicon case and controls LED lamps of architecture and lighting.
1.Automatically adapts input voltage DC12V-24V.2.Input standard DMX512 signal; 3-digital-display shows DMX address code.3.4 channels output; 4096 grey scales each; logarithmic dimming; lamplight soft & stable without strobe flash.4.DMX Master mode, slave mode available.5.Built-in 8 color changing modes and 10 speed scales.6.Indicator of the DMX512 signal receiving status.7.Power loss memory function.8.Wrong wiring protection at DMX port,over current protection and short circuit protection.
9. The DIN rail style design facilitates the installation of large-scale projects.Safety Warning:Please don’t install this controller in lightening, intense magnetic and high-voltage fields.1.To reduce the risk of component damage and fire caused by short circuit, make sure correct connection;2.Always be sure to mount this unit in an area that will allow proper ventilation to ensure a fitting temperature.
3.Check if the voltage and power adapter suit the controller(please select DC12-24V power supply with constant voltage);4.Don’t connect cables with power on; make sure a correct connecti)

Bővebb leírás

43 999 Ft‎

-52%

91 665 Ft‎

Hozzáadás a kívánságlistához

Egyéb infó

8X(Bc-835-Din-Rj45 Dc12-24V Input 5A X 5Ch Output, Din Rail 5Ch Cv Pwm Dmx5 H1E1

8X(Item Type:Dimmers; Features:DIN Rail 5CH DMX512 CV Decoder; Certification:ce,CCC,RoHS;Material: metal plastic; Model Number:BC-835-DIN-RJ45; Max. Load Power:300W(12V)/600W(24V);Input voltage:DC12V-DC24V; Max load current:5A*5CH; Grey Scale:4096 levels*5; Input Signal:DMX512/1990; Output Signal:Constant Voltage PWM; Decode Channel:5CH; DMX512 socket:RJ45; Dimension: L111xW46xH66(mm); Weight (G.W) : 135g; colour: White; Material: metal plastic;
It adopted advanced micro-computer control technology to transfer standard DMX512/1990 signal to PWM signal. user can choose 1~5 output channels, 4096 Grey Scales. It can be used as DMX512 master or as DMX decoder to connect computerized digital output console with analog silicon case and controls LED lamps of architecture and lighting.
1.Automatically adapts input voltage DC12V-24V.2.Input standard DMX512 signal; 3-digital-display shows DMX address code.3.4 channels output; 4096 grey scales each; logarithmic dimming; lamplight soft & stable without strobe flash.4.DMX Master mode, slave mode available.5.Built-in 8 color changing modes and 10 speed scales.6.Indicator of the DMX512 signal receiving status.7.Power loss memory function.8.Wrong wiring protection at DMX port,over current protection and short circuit protection.
9. The DIN rail style design facilitates the installation of large-scale projects.Safety Warning:Please don’t install this controller in lightening, intense magnetic and high-voltage fields.1.To reduce the risk of component damage and fire caused by short circuit, make sure correct connection;2.Always be sure to mount this unit in an area that will allow proper ventilation to ensure a fitting temperature.
3.Check if the voltage and power adapter suit the controller(please select DC12-24V power supply with constant voltage);4.Don’t connect cables with power on; make sure a correct connecti)
