USB to GPS Converter USB-Port-GPS Module Board for Raspberry Pi 3 Model B/ I6B2

With L80-39 GPS Chip inside, this USB-Port-GPS module will help you communicate satellite with UART or USB.It includes 66 search channels and 22 simultaneous tracking channels which helps acquire and track satellites in the shortest time at Outdoor.
With chip CP2102 working as the USB to UART Bridge chip, it works faster and more stable. It is compatilable with all models of Raspberry Pi which includes Raspberry Pi 3/Pi 2/B /A /B/A/Zero.
Features:
PPS output can be used to coordinate time with satellite. Internal patch antenna works quite well outdoor. Fix status LED blinks to show you when the GPS has determined the current coordinates
EASY, advanced AGPS technology without external memory. Time service application can be achieved by PPS sync NMEA feature. Built-in LNA for better sensitivity. RTC battery-compatible
Working Voltage:4.5-5.5V
100mA current draw to startup
Maximum Current: 100mA MAX
Working Temperature:-40~ 85 Celsius
Size:16.6x26x18.6(mm)
GPS:L80-M39
Patch Antenna Size:15.0 x 15.0 x 4.0mm
Position Accuracy:Less than 2.5M CEP
Velocity Accuracy:Less than 1.0m/s
Warm/cold start without ESEY:Less than 35s
Warm/cold start with ESEY:Less than 15s
Acquisition sensitivity:-148dBm
Tracking sensitivity:-165dBm
Update rate:1Hz (Default) up to 5Hz
Baud Rate:4800~115200 bps,9600bps default
Protocols:NMEA 0183
Mount Cable:1*8 Stacking Header USB micro data cable
Color: picture color
Material: PC metal
Package Contents: 1 x USB-Port-GPS Module with USB date wire(Raspberry Pi Board is not included)
