12 V NE555 késleltető relé (0-60s) - NE555 DC 12V késleltetési idő relé időzítő kapcsoló Állítható modul

A cím elején szereplő szín/minta/méret/típus kerül kiszállításra!
NE555 DC 12V Delay Time Relay Timer Switch Adjustable Module Digital LED Display 12V LED Display Delay RelayFeatures : 1.It's a new digital LED countdown display 12v delay module module. It can be widely used with various control switch places.2.It can set the delay time,can press "set" buttons.After setting up,power-up setting value is previous setting delay time as we set last time (power-down memory function);3.It's precision delay, error 0.01% per second, a delay of 0-999 seconds , LED changes per seconds ;
4.LED digital display, normally open trigger delay 12V relay module, triggered by an external signal.
5.Modules are high level trigger, counting time 0-999 seconds.
6.The wide range of products can be used in many fields;7.It work in a low-power mode, press the left button to turn off the digital display or begin to showDescriptions:
working voltage: DC 12V
Standby current:12ma
working current:50ma
Load: AC 250V 10A(max) or DC 30V 10A(max)Size:6.5x3.5cm Package Included: 1 x DC 12V LED Display Digital Delay Timer Control Switch Module PLC Automation TOP 12V NE555 Delay Relay(0-60s)
Feature:
This is a 12V Conduction delay relay module
- This is a brand new and high quality delay turn-on / Turn off module.the use of high-performance timing CPU design.
- the power indicator LED and switch trigger timing indication LEDs;
- The output can be connected to AC 250V 10A or DC 30V 10A load;
- There is the chronopotentiometry regulation time, adjustable from 0 to 60 seconds by default, or by changing the capacitance adjustment time longer Standby current: 5mA Action: 45mA For applications of Vehicle equipment-delay to prevent car ignition, prevention of high sudden current to burn components and devices.Parameter: 1.Module based on: NE555 chip.
2.Delay module: delay connect module
3.Input voltage: DC12V (DC 10v ~ 14.5v is okay.)
4.Control voltage: AC 0~250V / max. 10A, DC 0~30V / max. 10A the operating voltage: 12 volts DC; (otherwise 12V optional)
5.Max. load: 2200W
Main Chip (NE555) Characteristics: 1.Timing from microseconds to long hours
2.Simple circuit design
3.Precision Pulse Generation / Timing,
4.Adjustable Duty Cycle
5.Countless Application and Information SourcesPackage Include: 1 x DC 12V NE555 0~60 Seconds Delay Timer Time Switch Adjustable Time Relay Module 12V NE555 Delay Relay(0-10s)Features:This is a 12V Conduction delay relay module - This is a brand new and high quality delay turn-on module.the use of high-performance timing CPU design.
- the power indicator LED and switch trigger timing indication
LEDs;
- The output can be connected to AC 250V 10A DC 30V 10A
load;
- There is the chronopotentiometry regulation time, adjustable
from0 to 10 seconds by default, or by changing the
capacitanceadjustment time longerFor applications of
Vehicle equipment-delay to prevent car ignition, prevention of
high sudden current to burn components and devices.Specification:
1.Module based on: NE555 chip.
2.Delay modue:delay connect module
3.Input voltage: DC12V
4.Control voltage: AC 0~250V / max. 10A, DC 0~30V / max. 10A the operating voltage: 12 volts DC; (otherwise 5V optional)
5.Max. load: 2200WMain Chip (NE555) Characteristics:
1.Timing from microseconds to long hours
2.Simple circuit design
3.Precision Pulse Generation / Timing,
4.Adjustable Duty Cycle5.Countless Application and Information Sources
Package included1 x 12V Delay Adjustable Timer Relay Switch Module 0-10 Second NE555 Oscillator
