6X (nagy nyomatékú Rc szervó Dc12V24V 180Kg.Cm acél fogaskerék Asmc-04B Sz J4P3 robothoz)

6X(High Torque Rc Servo Dc12V24V 180Kg.Cm Steel Gear For Robot Asmc-04B Sz J4P3)

6X(Potentiometer control, remote control
Current adjustment and angle adjustment
CW and CCW switching, AD&PWM switching, pulse width 1-2ms&0.5-2.5ms
Compatible with Futaba, JR, SANWA, Hitec, etc.
No Load Current:Less than 500mA
Maximum Torque (Actual Measurement): 180kg.cm (24V); 1764N.cm (24V); 90kg.cm (12V); 882N.cm (12V)
Angular Velocity: 0.5s/60 degree, 24V; 1.0s/60 degree, 12V
Rotation Angle: 300degree MAX. (0-300degree, adjustable)
Input Mode: Pulse signal (remote controller, multi-channel controller, SCM); Analog voltage signal (potentiometer)
Pulse Signal Input Range: 0.5ms-2.5ms for all "multi channel controller", 1ms-2ms for drone remote controller, SCM program, Arduino etc.
Voltage Signal Input Range: 0-5V
Control Accuracy: 0.32 degree
Weight: 530g
Gear Material: Steel
Size: 95.5 x 60.5 x 102.6mm
Application: Robot, mechanical arm, other high torque control area
Power Input: DC12-24V
Motor 0utput: 12-24V
colour:Color as shown
Material:Metal PC
Package Contents:
1 * High Torque RC Servo)
